Connector Strip - Black

Black 12-way connector strips for terminating individual wires and joining them to a circuit or other system, so that one circuit can be linked to another. Each terminal in the row takes a single wire, which makes these strips well suited to semi-permanent connections that may later need inspecting, repairing, changing or having wires replaced.

They are used in everything from domestic wiring to industrial rack systems connecting to various I/O. The body is self-extinguishing, flame-proof polyethylene. Each terminal has a brass insert with a deep lead for easy cable entry and is clamped with a captive galvanised steel screw. Available in 3, 5, 10, 15 and 30 Amp ratings in packs of 10, and a 60 Amp rating supplied singly.

• Type: 12-way polyethylene connector strip
• Colour: Black
• Ratings: 3 Amp, 5 Amp, 10 Amp, 15 Amp, 30 Amp, 60 Amp
• Pack size: 10 (3 to 30 Amp); 1 (60 Amp)
• Body: Self-extinguishing, flame-proof polyethylene
• Inserts: Brass, with deep lead for easy cable entry
• Captive screws: Galvanised steel
• Operating temperature: -15°C to +80°C
