Red Heatshrink Ring Terminal (Pack of 25)
Usually dispatched within 1–2 working days. Free UK delivery over £75.00. 14-day returns.
- Main Description: These red heat shrink ring terminals provide a secure and durable electrical connection for a wide range of wiring applications.
- Manufactured with a copper conductor and tin-plated finish, they offer…
SKU: HWT37
Buying for a business?
EnquireAsk about bulk quantities and trade pricing.
Description
Main Description:
These red heat shrink ring terminals provide a secure and durable electrical connection for a wide range of wiring applications. Manufactured with a copper conductor and tin-plated finish, they offer excellent conductivity and corrosion resistance for long-term reliability.
The polyethylene insulation is lined with hot melt adhesive, creating a sealed connection when heated to help protect against moisture, dirt, and vibration. Featuring a 3:1 shrink ratio, these terminals provide enhanced sealing performance and are designed for low insertion force and easy crimping, ensuring a secure termination in demanding environments.
Technical Information:
- Colour: Red
- Wire Range: 0.5–1.5mm²
- Conductor: Copper
- Insulation: Polyethylene
- Plating: Tin
- Hot Melt Adhesive Lined
- Shrink Ratio: 3:1
- Shrink Temperature: +125°C to +180°C
- Operating Temperature: -45°C to +125°C
- Maximum Voltage: 600V
- Low Insertion Force
- Easy Crimping
- Secure Electrical Termination
Available Sizes:
- HWT37 – 4.4mm Stud Size
- HWT38 – 5.4mm Stud Size
- HWT39 – 6.6mm Stud Size
- HWT40 – 8.5mm Stud Size
- HWT80 – 10.6mm Stud Size
