Leak Off Pipe Overbraided (Petrol Pipe, Fuel Pipe) (5m)

Cotton overbraided fuel hose for automotive fuel systems running on unleaded petrol. Made to DIN 73379 Type B, it has a black NBR inner tube with polyester yarn reinforcement, so it holds up under pressure and stays flexible. The hose is also oil resistant.

The braided outer cover adds protection and gives the traditional look often wanted on older vehicles, so it works where appearance matters as well as function. Supplied in 5m coils. Not suitable for biofuels.

• Specification: DIN 73379 Type B
• Application: Automotive fuel hose (unleaded fuel)
• Inner tube: Black NBR
• Reinforcement: Polyester yarn
• Cover: Black, extrusion with braided surface
• Temperature range: -20°C to +70°C
• Working pressure: 10 bar (145 psi)
• Safety factor: 3:1
• Oil resistant: Yes
• Biofuels: Not suitable

Sizes (5m coils):

• 3.2 mm I.D. – 7 mm O.D.
• 5 mm I.D. – 10 mm O.D.
• 6 mm I.D. – 11 mm O.D.
• 8 mm I.D. – 13 mm O.D.
• 10 mm I.D. – 15 mm O.D.
