Green 2:1 Heat Shrink Tubing - Mini Reel Box

Green standard wall heat shrink tubing on a mini reel box, made from polyolefin and used for insulating electrical connections, bundling cables and protecting wires, pipes and other components. With a 2:1 shrink ratio, it recovers to about half its supplied internal diameter when heated, and the green colour makes it useful for colour-coding.

The tubing has good electrical and physical properties, high dielectric strength, and very good resistance to chemicals and solvents. It is flame retardant and resists fuel, hydraulic fluid and lubricating oil, so it suits automotive, electrical and industrial wiring. It is rated for operating temperatures from -55°C to +125°C.

• Type: Standard wall heat shrink tubing
• Colour: Green
• Material: Polyolefin
• Pack quantity: 1 coil
• Shrink ratio: 2:1
• Shrink temperature: 80°C
• Operating temperature: -55°C to +125°C
• Properties: Flame retardant, flexible, high dielectric strength
• Chemical resistance: Fuel, hydraulic fluid and lubricating oil
• Uses: Electrical insulation, cable bundling, and physical protection of pipes and wires

Sizes available (supplied internal diameter, coil length and recovered diameter):

• 1.2mm: 12m coil, recovers to 0.6mm
• 1.6mm: 12m coil, recovers to 0.8mm
• 2.4mm: 11m coil, recovers to 1.2mm
• 3.2mm: 11m coil, recovers to 1.6mm
• 4.8mm: 10m coil, recovers to 2.4mm
• 6.4mm: 9m coil, recovers to 3.2mm
• 9.5mm: 7m coil, recovers to 4.8mm
• 12.7mm: 6m coil, recovers to 6.4mm
• 19.1mm: 5m coil, recovers to 9.5mm
• 25.4mm: 3.5m coil, recovers to 12.7mm
