Blue Male Bullet 5mm Heatshrink (Pack of 25)
Usually dispatched within 1–2 working days. Free UK delivery over £75.00. 14-day returns.
- Blue heat shrink male bullet terminals for making sealed, crimped connections on 1.5–2.5mm² cable.
- Each terminal has a brass conductor with a copper tubular sleeve and a tin-plated finish, which helps conductivity…
SKU: HWT64
Buying for a business?
EnquireAsk about bulk quantities and trade pricing.
Description
Blue heat shrink male bullet terminals for making sealed, crimped connections on 1.5–2.5mm² cable. Each terminal has a brass conductor with a copper tubular sleeve and a tin-plated finish, which helps conductivity and resists corrosion.
The polyethylene insulation is lined with hot melt adhesive. Once heated, it shrinks down at a 3:1 ratio and seals the joint against moisture, dirt and vibration. The terminals have a low insertion force and crimp easily, so they give a secure termination in harsh conditions. Supplied in a pack of 25.
- Colour: Blue
- Bullet size: 5mm
- Wire range: 1.5–2.5mm²
- Conductor: Brass
- Sleeve: Copper tubular
- Insulation: Polyethylene, hot melt adhesive lined
- Plating: Tin
- Shrink ratio: 3:1
- Shrink temperature: +125°C to +180°C
- Operating temperature: -45°C to +125°C
- Maximum voltage: 600V
- Low insertion force and easy crimping
- Pack quantity: 25
